The PC200x300 hammer crusher is a compact and efficient crushing machine designed for small to medium-scale crushing tasks. It is widely used in mining, cement, coal, metallurgy, and construction industries to crush brittle materials with medium hardness.
1. Technical Specifications
Feeding Size: ≤100 mm
Output Size: 0–10 mm
Capacity: 1–3 tons/hour
Motor Power: 7.5–11 kW
Rotor Diameter: 200 mm
Rotor Length: 300 mm
Weight: ~800 kg
2. Main Components
Hammer Head: High manganese steel, wear-resistant
Rotor: High-speed rotating shaft for impact force
Crushing Chamber: Lined with durable plates
Frame: Compact and easy to install
Motor and Base: Stable operation and low vibration
3. Working Principle
When the crusher is in operation, the motor drives the rotor to rotate at high speed. The hammers on the rotor impact the material, breaking it by collision and shear force. Crushed material then passes through the screen plate and is discharged from the outlet.
4. Product Features
Compact size, easy to move and install
Simple structure, easy maintenance
High crushing ratio and uniform particle size
Low energy consumption, high efficiency
Suitable for dry and slightly wet materials
Hammer Crusher Specific specifications
| Model |
Max feeding size(mm) |
Max output size(mm) |
Capacity (t/h) |
Motor Power(kw) |
Weight(kg) |
| PC200*300 |
150 |
15 |
1-3 |
7.5 |
400 |
| PC400*300 |
200 |
15 |
5-10 |
11 |
800 |
| PC600*400 |
250 |
15 |
10-25 |
22 |
2260 |
| PC600*600 |
250 |
15 |
15-30 |
37 |
3200 |
| PC800*600 |
250 |
15 |
20-35 |
55 |
4800 |
| PC1000*800 |
— |
— |
— |
— |
— |
